DTJ300導熱硅脂點膠機運行要留意三方面
一是注意涂膠的質量
First, pay attention to the quality of gluing
DTJ300導熱硅脂點膠機的點膠閥的正確選擇除了可以提高點膠機的點膠效果外，所用膠水的質量也會影響點膠效果，很檢查膠水的整體質量如何更好。如果發現使用的膠水雜質過多，很好從頭更換，這樣可以避免點膠問題的機會。
The correct selection of the dispensing valve of dtj300 thermal conductive silicone grease dispenser can not only improve the dispensing effect of the dispenser, but also affect the dispensing effect. It is important to check the overall quality of the glue. If you find that there are too many impurities in the glue used, it is good to replace it from the beginning, so as to avoid the opportunity of dispensing problems.
二是注意點膠參數的設置
Second, pay attention to the setting of dispensing parameters
在點膠產品前，您可以根據產品門店的實際需求，通過手持體驗盒設置點膠路線、操作參數等。點膠機配備手持體驗盒。設定操作參數時，需要根據所用膠水的粘度和產品對出膠量的需求進行調整。拉膠現象影響點膠機的涂膠效果。
Before dispensing products, you can set dispensing routes and operating parameters through the handheld experience box according to the actual needs of the product store. The dispenser is equipped with a handheld experience box. When setting operating parameters, it is necessary to adjust the glue output according to the viscosity of the glue used and the product demand. The glue pulling phenomenon affects the glue application effect of the dispenser.
三是注意點膠閥的選擇
Third, pay attention to the selection of dispensing valve
DTJ300導熱硅脂點膠機主要對產品進行點膠和涂布操作。這種操作方式需要點膠閥的配合才能完成，所以點膠閥類型的選擇是一個非常重要的細節。點膠機上可以安裝的點膠閥有很多種。除了點膠閥外，還可以通過安裝吸入式點膠閥來提高點膠效果。吸膠式點膠閥吸膠效果很佳。在點膠機上安裝吸膠式點膠閥，可以很好的吸回膠水，避免滴膠和漏膠等問題影響涂膠效果。
Dtj300 thermal conductive silicone grease dispenser is mainly used for dispensing and coating products. This operation mode requires the cooperation of the dispensing valve, so the selection of the dispensing valve type is a very important detail. There are many kinds of dispensing valves that can be installed on the dispenser. In addition to the dispensing valve, the dispensing effect can be improved by installing the suction dispensing valve. The suction dispensing valve has good suction effect. The glue dispensing valve installed on the dispenser can well suck back the glue to avoid glue dripping and leakage, which will affect the gluing effect.
此外根據膠水的工藝和特性，點膠機在點膠過程中會配備不同的閥體。有幾種不同類型的分配閥。那么同一個閥門使用的原因不一樣是怎么回事？
In addition, according to the process and characteristics of the glue, the dispenser will be equipped with different valve bodies during the dispensing process. There are several different types of distribution valves. What is the reason why the same valve is used for different reasons?
閥門使用問題：針式點膠
Valve use problem: needle dispensing
1、轉動桿損壞，使閥體不能關緊。2、密封圈損壞，使閥體不能關緊。3、復位彈簧片損壞，使閥體不能形成負壓。
1. The rotating rod is damaged so that the valve body cannot be closed tightly. 2. The sealing ring is damaged, so that the valve body cannot be closed tightly. 3. The return spring is damaged, so that the valve body cannot form negative pressure.
膠閥使用問題：不產生膠水。
Use problem of glue valve: no glue is produced.
1、檢查膠桶中的膠水是否不夠。2、檢查橡膠管路是否堵塞。3、檢查點膠閥的流膠裝置是否沒有堵塞。4、檢查點膠閥是否有氣壓供應。5、檢查復位彈簧片是否不能移動。
1. Check whether there is insufficient glue in the glue barrel. 2. Check whether the rubber pipe is blocked. 3. Check whether the glue flow device of the dispensing valve is not blocked. 4. Check whether the dispensing valve is supplied with air pressure. 5. Check whether the return spring cannot move.
膠閥使用中的問題：不要停膠。
Problems in the use of glue valve: do not stop glue.
1、
雙組份打膠機廠家認為點膠閥的傳遞桿或關閉裝置損壞。2、點膠閥的供氣壓力不能中斷。
1. The manufacturer of the two-component glue applicator thinks that the transfer rod or closing device of the dispensing valve is damaged. 2. The air supply pressure of the dispensing valve cannot be interrupted.
